Name	Fully-Automatic Double-deck & Double-chamber Laminator
Model	BSL2436DD01
Equipment Parameters	Power Supply	AC380V 3phase 5 line	Control Board	Touch Screen
	Total Power	210KW（exclude vacuum pump）	Normal working Power	≈120KW
	Effective Laminating Area	2400×3600	Chamber Layout	Double-deck Double-chamber
	Compressed air flow	≥400L/min	Weight	≈43T

Main Technique Parameters

Effective Laminating  Area         2400 mm × 3600mm×4

Overall Dimension                 17700mm×3540mm×2900mm

(only laminator exclude auxiliary tools such as vacuum pump and heating station）

Heating type                      heating transfer oil

Compressed Air Pressure          0.6～0.8MPa

Working Vacuum Degree           100～40Pa

Evacuation Speed                 ≥70L/S

Precision of Temperature Control    ±1.5℃

Temperature control range          Room Temperature--180℃

Temperature Uniformity             Laminating area≤±2℃

Height of laminating chamber        30mm

Evacuation Time                   Depending on the process, suggesting: 5～8min

Cover moving range                200mm
